Part number: 1C49 5LT Manufacturer SKU: 51545
For current pricing and to place an order please contact your Ellsworth Customer Service Representative.
Call Us Contact Customer Service at +65 9386 6411。
Live Chat Speak with one of our Technical Service Personnel.
Request a Quote Submit a quote request and a Sales Representative will contact you.
Send an Email We will respond within 1 business day.
-
DescriptionHumiSeal® 1C49 Silicone Conformal Coating is a moisture curing, VOC and solvent free silicone coating that is used for circuit assemblies. It offers excellent flexibility, moisture and environmental protection. It fluoresces under UV light to aid inspection and can be applied by spraying, brushing, or dipping methods. 5 L Jug.
-
Product Details
Typical Use: A silicone coating for printed circuit assemblies, 1C49 is solvent free, and has no significant VOC. The final film demonstrates excellent flexibility and is repairable. Chemical Composition: Silicone Color: Clear Components: 1 part Cure System: Room Temperature/Heat Cure Time: 24h @ room temperature; 20min @ 76 °C Flash Point: 102 °C Key Specifications: HumiSeal 1C49™ is MIL-I-46058C qualified, IPC-CC-830 and RoHS Directive 2002/95/EC compliant, and recognized under UL File Number E105698. Specific Gravity: 1.1 Tack Free Time: 3 to 5h Viscosity: 9,000 ± 1,500 -
SDS / TDS
