Part number: 184 CURING AGENT 20.4KG PL Manufacturer SKU: 2120925
For current pricing and to place an order please contact your Ellsworth Customer Service Representative.
Call Us Contact Customer Service at +65 9386 6411。
Live Chat Speak with one of our Technical Service Personnel.
Request a Quote Submit a quote request and a Sales Representative will contact you.
Send an Email We will respond within 1 business day.
-
DescriptionDow SYLGARD™ 184 Clear is a two component, flowable, room temperature and heat cure silicone curing agent with good dielectric properties and flame resistance. Curing agent only. It is to be used with Dow SYLGARD™ 184 Base to form a flexible, encapsulant that is used to protect electrical applications. 20.4 kg Pail.
-
Product Details
Typical Use: Typically used for LED lighting encapsulation, power supplies, connectors, sensors, industrial controls, transformers, amplifiers, high voltage resistor packs, relays, solar cells and adhesive handling beam lead integrated circuits during processing. Brand: SYLGARD Chemical Composition: Silicone Color: Clear Components: 2 part Cure System: Room Temperature/Heat Cure Time: 48h @ 25 °C; 35min @ 100 ºC; 20min @ 125 ºC; 10min @ 150 ºC Dielectric Strength: 19 kV/mm Flash Point: > 101.1 ºC Mix Ratio: 10:1 Service Temperature: -45 to 200 °C Specific Gravity: 1.03 Tensile Strength: 980 psi Thermal Conductivity: 0.27 W/mK Viscosity: Mixed: 3500 Volume Resistivity: 2.9 x 10^14 ohm-cm Working Time: 1.5 @ 25 °C -
